Standard equipment

• • Complete projector built in for quality control with 10 power lens
• • Point thinning attachment with built-in drive and flex drive cable
• • Built-in wheel setup stop
• • Built-in diamond dresser
• • Operator Manual
• • “NEW LED LIGHTING SYSTEM” Installed

Specifications

• Materials HSS (CBN Wheel required)
• Materials Carbide Tipped - solid carbide (Diamond Required)
• Grinding Capabilities Point Angle 80 degrees to 150 degrees (180 for flat bottom 80 - 130 for left hand) Cutting Angle (-10 degree) 0 degree - 40 degree infinitely adjustable
• Motor 1/3 HP - 115 Volt Single Phase - Point thinning attachment 7000 RPM
• Dimensions 17 x 14 x 18 approximate

Optional : Complete Vac system (to be quoted at the time of purchase)

Terms: 50 % to accompany the Purchase order with the balance paid prior to shipping (“FIRST COME FIRST SERVICE”)

Warranty Mechanical 1 year - Electrical 90 days

FOB Butler, PA

Call: (724) 287-2529

(724) 287-2529
